Gefen EXT-HD-3G-C HDMI to 3G-SDI Converter

Maximum Resolution

Input: 1080p60 Output: 1080p 10-bit support on input and output

Color Spaces Supported

HDMI YCbCr 4:4:4 DVI RGB 4:4:4 Up to 10-bit

Audio Support

LPCM up to 7.1 channels

Clock Speed

Max Pixel Clock: 150 MHz Maz TMDS Clock: 225 MHz

I/O Connections

1 x SDI (BNC) female input 1 x Locking HDMI Type A female output 1 x USB mini-B 1 x 3-pin locking power connector

Dip Switches

5 x DIP configuration switches

LED Indicators

1 x Green LED 1 x Blue LED

Power Supply

12 VDC nominal (6 to 24 VDC operating range)

Power Consumption

2 W maximum

Operating Temperature

Storage Temperature

Operating Humidity

5 to 90% RH (non-condensing)

Storage Humidity

0 to 95% RH (non-condensing)

Dimensions

2.9 x 1.2 x 2.3" / 74 x 30 x 59 mm

Weight

0.3 lb / 150 g

Package Weight

1.31 lb

Box Dimensions (LxWxH)

10.5 x 6.9 x 4"
