Datavideo HS-2000 Mobile Studio

Number of Channels

2

File Format

Broadcast Wave (BWF) and Waveform Audio (WAV)

File System

Fat32 for cards 4 GB or more Fat16 for cards 2 GB or more

Recording Media

Up to two CompactFlash memory cards

Bit Depth

16-bit, 24-bit

Sampling Frequencies

Clock Reference Input

INTERNAL, WORD IN, VIDEO IN, DIGITAL IN

Timecode

23.976, 24, 25, 29.97DF, 29.97NDF, 30DF, 30NDF

Analog Input

2 x XLR, balanced

Input Impedance

4.3 k?

Nominal Input Level

Maximum Input Level

+15 dBu (4.36 Vrms) digital reference level: -9 dBFS, analog input: +6 dBu +18 dBu (6.16 Vrms) digital reference level: -14 dBFS, analog input: +4 dBu +20 dBu (7.75 Vrms digital reference level: -16 dBFS, analog input: +4 dBu +22 dBu (9.76 Vrms) digital reference level: -18 dBFS, analog input: +4 dBu +24 dBu (12.3 Vrms) digital reference level: -20 dBFS, analog input: +6 dBu -6 dBu (0.388 Vrms) digital reference level: -14 dBFS, analog input: -20 dBu -4 dBu (0.489 Vrms) digital reference level: -16 dBFS, analog input: -20 dBu -2 dBu (0.616 Vrms) digital reference level: -18 dBFS, analog input: -20 dBu 0 dBu (0.775 Vrms) digital reference level: -20 dBFS, analog input: -20 dBu selectable

Analog Output

2 x XLR L/R balanced line 2 x XLR balanced monitor 1 x 1/4" stereo headphone

Output Impedance

Line: 100 ? or less Monitor: 100 ? or less

Nominal Output Levels

Maximum Output Level

Line +15 dBu (4.36 Vrms) digital reference level: -9 dBFS, analog output: +6 dBu +18 dBu (6.16 Vrms) digital reference level: -14 dBFS, analog output: +4 dBu +20 dBu (7.75 Vrms) digital reference level: -16 dBFS, analog output: +4 dBu +22 dBu (9.76 Vrms) digital reference level: -18 dBFS, analog output: +4 dBu +24 dBu (12.3 Vrms) digital reference level: -20 dBFS, analog output: +4 dBu -6 dBu (0.388 Vrms) digital reference level: -14 dBFS, analog output: -20 dBu -4 dBu (0.489 Vrms) digital reference level: -16 dBFS, analog output: -20 dBu -2 dBu (0.616 Vrms) digital reference level: -18 dBFS, analog output: -20 dBu 0 dBu (0.775 Vrms) digital reference level: -20 dBFS, analog output: -20 dBu Monitor +15 dBu (4.36 Vrms) digital reference level: -9 dBFS, analog output: +6 dBu +18 dBu (6.16 Vrms) digital reference level: -14 dBFS, analog output: +4 dBu +20 dBu (7.75 Vrms) digital reference level: -16 dBFS, analog output: +4 dBu +22 dBu (9.76 Vrms) digital reference level: -18 dBFS, analog output: +4 dBu +24 dBu (12.3 Vrms) digital reference level: -20 dBFS, analog output: +4 dBu

Phones

Connector: 1 x 1/4" (6.3mm) Stereo Jack Maximum Output level: 45 mW + 45mW or more (THD+N 0.1% or less. into 32 ?)

Frequency Response

Digital Input

Digital Output

SMPTE

1 x XLR Balanced Timecode Input 1 x XLR Balanced Timecode Output

BNC Connector

CONTROLS

1 x PS/2 Keyboard Input 1 x Ethernet 1 x RJ-45 Remote Input for TASCAM RC-HS20PD or RC-HS32PD only 1 x D-Sub for RS-422, RS-232C, and Parallel Inputs 1 x USB 2.0 Host Output

Remote Control Connector

etherCON (CAT6 compatible) Power supply voltage: 13 V/41 V Signal: LVDS serial

Ethernet Connector

RJ-45 Supported Standards: 100BASE-TX, 1000BASE-T

Keyboard Connectors

Mini-DIN (PS/2)

USB Connector

USB A-type 4-pin Protocol: USB 2.0 HIGH SPEED (480 Mbps)

Display

3.5" TFT Tilt Touch Screen

Display Resolution

320 x 240 pixels

Distortion

0.005% or less (recording and playback)

S/N Ratio

100 dB or more (recording and playback)

Power

100 to 240 VAC, 50-60Hz

Power Consumption

25 W

Operating Temperature Range

Dimensions

19 x 3.7 x 12.5" (48 x 9.4 x 32 cm)

Weight

11.2 lb (5.1 kg)

Package Weight

15.1 lb

Box Dimensions (LxWxH)

22 x 15.85 x 7.21"
