Eaton Tripp Lite Series DRS-1215 14-Outlet Economy Network Server Surge Protector, 15 ft. 4.57 m Cord, 3000 Joules, 1U Rack-Mount

Rating

UL1449: 330 V

EMI / RFI Filtering

40 to 80 dB

Immunity

Conforms to IEE 587 / ANSI C62.41

Certification

Tested to UL1449 3rd Edition by ETL, Approved for Canada by ETL, Exceeds IEEE 587 category A&B specifications

Nominal Input Voltage

Supported: 120 VAC

Recommended Electrical Service

120 V (110 to 125 V)

Connection Type

NEMA 5-15P input plug

Cord Length

15.0' (4.6 m)

Voltage Compatibility

120 VAC

Surge

Maximum Amps: 120,000

Frequency Compatibility

50 / 60 Hz

Output Watts

1,800

Circuit Breaker

15 A

Outlet

Quantity / Type: 14 (6 front NEMA 5-15R / 8 rear)

Switches

Power switch controls power to all outlets

Locking Switch Cover

Transparent locking switch cover prevents accidental shutoff

AC Suppression

3,000 J

AC Suppression Response Time

<1 ns

Protection Modes

Includes full normal mode (H-N) and common mode (N-G / H-G) line surge suppression

Clamping Voltage (RMS)

140

Material of Construction

Metal

Style

Rack mount

Form Factors Supported

1U rack mount, 0 U vertical rack mount, wall mount and under-counter mounting supported; detachable flanges can be re-configured to support a variety of additional mounting options

Distance

Between Front Outlets: 1.5" (39.0 mm) Between Rear Outlets: 1.5" (39.0 mm)

Dimensions

1.75 x 17.50 x 4.00" (4.45 x 44.45 x 10.16 cm)

Weight

4.6 lb (2.1 kg)

Package Weight

6 lb

Box Dimensions (LxWxH)

20.5 x 9.5 x 2.1"
